Hollow 0.6kg Electromagnetic Powder Clutch FL6K 6N.M 24V Input
Introduction
Magnetic clutch can transmit torque based on electromagnetic theory
and the use of magnetic powder. It has advantages of fast response,
simple structure, no pollution, no noise, no shock and vibration,
energy-saving and so on. It is a versatile, superior performance of
automatic control components. Magnetic clutch can also be used to
buffer starting, overload protection, speed control and so on
Details for clutch
| Type | Hollow magnetic powder clutch |
| Model | FL6K |
| Torque | 6NM/0.6kg |
| Input | DC24V |
| Current | 0.8A |
| Type | Powder clutch |
| Warranty | 1 year |
Parameters
| Model | Torque/N.m | Current/A | Voltage/V | Speed/rpm | Weight/kg |
| FL6K | 6 | 0.80 | 24 | 1400 | 4.0 |
| FL12K | 12 | 1.00 | 24 | 1400 | 6.5 |
| FL25K | 25 | 1.50 | 24 | 1400 | 9.5 |
| FL50K | 50 | 1.80 | 24 | 1000 | 15.0 |
| FL100K | 100 | 2.00 | 24 | 1000 | 32.0 |
| FL200K | 200 | 2.80 | 24 | 1000 | 50.0 |
| FL400K | 400 | 3.00 | 24 | 1000 | 91.0 |
| Model | D0(mm) | D1(mm) | D2*L1(mm) | D3*L2(mm) | D4(mm) | L3(mm) | L4(mm) | L5(mm) | d(mm) | t(mm) | 6-S2(mm) | 6-S1(mm) | Magnetic powder(g) |
| FL6K | 130 | 50 | 60*16 | 65*7 | 70 | 64 | 91 | 3 | 16 | 5 | M4 | M5 | 10 |
| FL12K | 157 | 60 | 70*18 | 72*8 | 80 | 77 | 107 | 3 | 20 | 6 | M4 | M5 | 20 |
| FL25K | 182 | 71 | 80*20 | 82*10 | 97 | 88 | 129 | 4 | 25 | 8 | M5 | M6 | 30 |
| FL50K | 219 | 85 | 95*22 | 97*11 | 110 | 105 | 147 | 4 | 30 | 8 | M6 | M6 | 60 |
| FL100K | 290 | 105 | 125*24 | 128*14 | 145 | 134 | 182 | 5 | 35 | 10 | M8 | M8 | 110 |
| FL200K | 335 | 125 | 140*28 | 145*17 | 165 | 145 | 200 | 5 | 45 | 14 | M8 | M10 | 180 |
| FL400K | 398 | 160 | 180*30 | 190*20 | 210 | 193 | 251 | 5 | 60 | 18 | M10 | M12 | 300
|
Application
Printing machine
Paper making machine
Packaging machine
Plastics machine
Rubber machine
Textile machine
Other machines
Featured advantages
1. Fast response. Instant and fast reaction to commands.
2. Costly. Excellent heat dissipation and quality materials mean long life,
even under high frequency and high tempreture conditions.
3. Easy to install. No dust brush is needed, and operation is simper and easier.
4. No need adjust of the motor. No need adjustment for the motor, and once it is installed only very minor adjustments are needed.
5. Adjustable torque. Torque levels can be increased or decreased by changing the
current, making it suitable for a variety of applications.
