Small Runout Aluminum Dead Shaft Idler Roller For Printing Machine Guiding Use
Summary
Aluminum dead shaft idler roller is also called aluminum roller, it is made of advantaged aluminum alloy material. It has all kinds of modules and sizes. Inside the roller, there is a strong rib structure, chich is very fixed. And the Omni-axes is controlled by dynamic balance correction treatment, which limits to 2g. with the special cutting method, the roll surface's lustrousness is from 1.6 to 0.8, and coaxially is 0.02mm. the axle end under technology processing and with best bearing, though it is running with high speed, it still works well. according to different industry, the roller can also be used in anodic oxidation HV300, HV700, Teflo, it can bear the stuff working surrounding.
CBB brand Aluminum dead shaft idler roller is with High strength, Small resistance, Light weight, Flexible rotation, and no rusting. It is widely used in spinning, electric wire and cable, metal-processing industry, paper industry, rubber industry, plastics industry and mechianical industry.
| OD | ID | Wall Thickness | Ribs mark | Strong ribs |
| 25 | 18 | 3.50 | A1 | |
| 28 | 22 | 3.00 | A1 | |
| 30.1 | 20.1 | 5.00 | A1 | |
| 33.8 | 25.4 | 4.20 | A1 | |
| 38.2 | 30.2 | 4.00 | A1 | |
| 40.1 | 30.1 | 5.00 | A1 | |
| 45.1 | 32 | 6.50 | A1 | |
| 50 | 40 | 5.00 | A1 | |
| 51.4 | 38.8 | 6.30 | A2 | 3 |
| 52 | 44.6 | 3.70 | A1 | |
| 55 | 45 | 5.00 | A1 | |
| 60 | 50 | 5.00 | A1 | |
| 70 | 61 | 4.50 | A1 | |
| 71 | 64.6 | 3.20 | A2 | 7 |
| 75 | 66 | 4.50 | A1 | |
| 75 | 60 | 7.50 | A1 | |
| 76.2 | 69.8 | 3.20 | A2 | 7 |
| 77.4 | 70 | 3.70 | A2 | 9 |
| 80.7 | 70.3 | 5.10 | A2 | 9 |
| 81 | 73.2 | 4.00 | A2 | 9 |
| 90.5 | 82.9 | 3.80 | A2 | 9 |
| 90.6 | 75.6 | 7.50 | A1 | |
| 101 | 92.4 | 4.30 | A2 | 9 |
| 101 | 90.2 | 5.40 | A2 | 9 |
| 110 | 101 | 4.50 | A2 | 9 |
| 120.9 | 109.1 | 5.90 | A2 | 9 |
| 121 | 111.6 | 4.70 | A2 | 9 |
| 130 | 120 | 5.00 | A2 | 9 |
| 150.5 | 136.5 | 7.00 | A1 | |
| 150.9 | 136.9 | 7.00 | A3 | 8 |
| 151 | 140 | 5.50 | A2 | 10 |
| 200 | 186 | 7.00 | A1 | |
| 320 | 296 | 12.00 | A1 | |
CBB brand new aluminum dead shaft idler roller is best choice for low-inertia, low-tension applications, with dynamic balanced, idler roller will be free running performance, especially good for high speed gravure printing machine and flexo printing machine.
| Diameter | 22-320mm |
| Length | 100-6000mm |
| Weight | 1-100kg |
| Anodize | HV300/HV700 |
| Thickness of anodize | 20-80μm |
| Type | Dead shaft roller |
| Surface | Plain/ Cross line/ Center line/ Groove line |
| Smoothness | Ra6.3-0.4 |
| Balancing | G2.5 |
Advantage of CBB Brand Aluminum dead shaft idler roller
Good material
High quality of 6063 T6 and 6061 T6 material will make the stable quality of the aluminum alloy guide roller.
Ribs inside the material can make the roller stronger.
High quality of Carbon steel shaft will help customer's machine more stable.
Delicate and smooth
Proper smoothness (Or according to customers inquiry) of the surface and groove will reduce web slippage and get better tension control. Reduce bearing side-thrust.
Anodized of the roller will make the idler rollers life much longer.
Multiple choices
Variety of styles, fair prices, complete specifications.
Customized is available.
About CBB Chuangbo:
Ruian Chuangbo Machinery Co., Ltd. established in 1995, is located in Nanbin Street Industrial Zone, Ruian City, Zhejiang Province, China
The company is specialized in manufacturing of machinery parts. Our main products include aluminum idler roller, air expanding shaft, centrifugal blower, powder brake/clutch, and other machine parts.
