Foot Mount Type Steel Safety Chucks STO/STW 75 Shaft 75mm Pillow
Type
Introduction
Safety chuck is a quick-connecting device that is applied to the
receiving and discharging reels to save time for the operator to
load and unload. There is no need to move the structure of the
machine every time when changing materials. The safety chuck
provides the operator with the ability to quickly change materials
when receiving and discharging. Reduce the time of the upper and
lower materials, making the operator's work more efficient to
achieve cost savings.
THE BIGGEST MODEL IS TYPE 230!
Product details
| Model Type: STO/STW 75 |
| Maximum load | Maximum torque | Square bar size | Weight |
| 7000kg | 235 KGFM | 55~75MM | 120kg |
| Application | Printing machinery |
| Bag making machinery |
| Paper machinery |
| Wire and cable machinery |
| Roll of wire machinery |
| Bundle bag machinery |
Textile machinery
Weaving machinery |
| Woodworking machinery |
| Other machinery |
| Size | Maximum load | Maximum torque | Standard square bar size | Unit Weight |
| FLO/FLW STW/STO 28 | 800 kg | 18 KGFM | 25/30 mm(22~30 mm avaiable) | 18 KG |
| FLO/FLW STW/STO 35 | 1600 kg | 35 KGFM | 32/38 mm (30~4O mm avaiable) | 27 KG |
| FLO/FLW STW/STO 50 | 2800 kg | 110 KGFM | 40/45/50 mm (40~50 mm avaiable) | 53 KG |
| FLO/FLW STW/STO 75 | 7000 kg | 235 KGFM | 55/65/75 mm (50~80 mm avaiable) | 120 KG |
| FLO/FLW STW/STO 90 | 12000 kg | 1000 KGFM | 80~120 mm | 300 KG |
| FLO/FLW STW/STO 120 | 22000 kg | 2000 KGFM | 120~180 mm | 600 KG |
| FLO/FLW STW/STO 180 | 32000 kg | 2500 KGFM | 170~200 mm | 1000 KG |
| FLO/FLW STW/STO 230 | 64000 kg | 4100 KGFM | 170~230 mm | 1200 KG |
Features
1. Safety chuck is simple, practical and easy to install
2. Chuck nickel processing, mount the components sclerosis
treatment, durable.
3. With imports of used heavy bearings, to ensure that the heavy
load, high-speed application of occasions have good performance.
4. Parts mount a reasonable tolerance so as to ensure that torque
transmission in the process of smoothing a row.
5 . The safety chuck is a quick-connecting device that is applied
to the receiving and discharging reels to save time for the
operator to load and unload.
Advantage
1. The overall structure of the safety chuck is reasonable and
rigid, which can withstand greater torque and eliminate the
phenomenon of loosening in rotation.
2. The use of special properties of super alloy steel materials,
superior durability, durability;
3. Bayonet nickel plating treatment, bayonet after hardening
treatment, high hardness, strong and durable, can ensure good
performance in heavy load, high speed applications;
4. Reasonable tolerance fit of bayonet parts ensures smooth and
continuous torque transmission process, greatly enhancing the
safety performance of machinery.
5. Simple installation, suitable for continuous sliding or high
frequency use, buffer starting, with soft starting characteristics.
Mount
| SIZE | A | B | C | D | E (f7) | E-F | H-G | K |
| Type 28 | 61 | 8 | 4 | 28 | 25.3 | 0.15 | 0.5 | 1 |
| Type 35 | 73 | 18 | 5 | 30 | 32.38.40 | 0.2 | 0.5 | 1.5 |
| Type 50 | 81 | 13 | 5 | 32 | 40.45.50 | 0.3 | 0.5 | 2 |
| Type 75 | 106 | 16 | 6 | 40 | 55.65375 | 0.4 | 0.5 | 3 |
Countersink Information for Flange Mounted Type
| SIZE | ϕ A | ϕ B | C | D |
| FLO/W 28 | 18 | 11 | 15 | 7 |
| FLO/W 35 | 20 | 13 | 16 | 8 |
| FLO/W 50 | 26 | 18 | 22 | 10.5 |
| FLO/W 75 | 20 | 14 | 27 | 8 |
Why choose CBB Chuangbo
A. Reliable supplier in China
Established in 1995, CBB Chuangbo has been in machinery parts for
25 years, now we are biggest manufacturer of machinery parts in
East China.
B. Hight quality material
High quality of steel shell for the brake and imported powder for
longer life of the brake.
C. Cooling treatment
Insider there is a small cooling fan inside the brake, cooling the
tempreture and make the brake stable.
D. Quality control
We have the quality control system during the whole production
fromthe very beginning to the end and our principle is to make sure
each shaft is qualified.
