| Type | Power | Flow Rate | Total Pressure Pa | Noise | Rorate Speed | Voltage |
| KW | M 3 /h | | ≤ DB(A) | r/min | V |
| DF-2 | 0.18 | 406 | 450 | 72 | 2840 | 380 |
| DF-3 | 0.25 | 504 | 860 | 75 | 2840 | 380 |
| DF-4 | 0.37 | 660 | 850 | 76 | 2840 | 380 |
| DF-5 | 0.55 | 850 | 1020 | 76 | 2840 | 380 |
| DF-6 | 0.75 | 1200 | 1210 | 78 | 2840 | 380 |
| DF-7 | 1.1 | 1650 | 1260 | 80 | 2840 | 380 |
| DF-8 | 1.5 | 2300 | 1400 | 82 | 2840 | 380 |
| DF-9 | 2.2 | 2800 | 1650 | 82 | 2840 | 380 |
| DF-10 | 3 | 3000 | 1700 | 82 | 2840 | 380 |
| DF-11 | 4 | 3200 | 1750 | 82 | 2840 | 380 |
| DF-12 | 5.5 | 3400 | 1800 | 84 | 2840 | 380 |
Advantages
· The Fan with Compact structure.
· The impeller will do by dynamic balancing tests. It greatly
improves the stability of the impeller operation, and reduces the
vibration and noise.
· The Fan with advantages of small volume, light weight, angle
adjustable and convenient for installation and maintenance.
· Transportation gas temperature at -20℃ ~ 80℃.
· Fan Material is optional according to your need.
· Customzation is acceptable.
Application
· For building cooling system.
· For machinery cooling, such as printing machines, slitting
machines, lamination machine and so on.
· For other places need cooling the air.
Professional Service
1. Our products be export to more than 30 countries.
2. On time delivery.
3. The experienced customers service team provides excellent
communication for all customers to answer questions and solve
problem.
About CBB Chuangbo
Ruian Chuangbo Machinery Co., Ltd. established in 1995, is
specialized in manufacturing of machinery parts. The company has
advanced production level and scientific research equipment, the
products are matched with printing, packaging, plastics, paper,
textile, pharmaceutical machinery and other industries. The company
has been granted with independent import and export rights, the
products sold to allover the country and export to more than thirty
countries and regions, such as: India, Pakistan, Israel, Russia,
Spain and so on.
